GENERAL FEATURES
1. LCD display screen, clear display.
2. It is suitable for laboratory potentiometric titration.
3. Support three titration modes: Auto Titration (Preset Endpoint Titration), Manual Titration and Control Titration.
4. Auto Titration allows to set the endpoint, range and delay time.
5. Manual titration allows to add continuously or add small amount.
6. Controlled titration allows to set the endpoint and switch titration speed with manual titraion.
7. pH calibration and measurement are supported.
8. pH supports automatic or manual calibration.
9. 1-2 points calibration for pH with standard recognition.
10. Automatic/Manual temperature compensation ensures pH accurate results.
11. Automatic electrode diagnosis with pH slope.
12. An external 10mL or 25mL glass burette can be used for volume measurement (prepared by user).
Includes
1. JB-11 Stirrer
2. E-201F pH composite electrode
3. T-818-Q Temperature probe
4. 216-01 Silver electrode
5. 217-01 Reference electrode
6. pH standard powder (4.01, 7.00, 10.01)
|
Model |
Ti-21 |
|
|
mV |
Range |
(-1400~1400)mV |
|
Resolution |
1mV |
|
|
Accuracy |
±0.35%FS(±4.9mV) |
|
|
Titration control sensitivity |
±5mV |
|
|
pH |
Range |
(0.00~14.00)pH |
|
Resolution |
0.01pH |
|
|
Accuracy |
±0.03pH |
|
|
Titration control sensitivity |
±0.1pH |
|
|
Temperature |
Range |
(0.0~100.0)ºC |
|
Resolution |
0.1ºC |
|
|
Accuracy |
±0.3ºC |
|
|
Instrument Accuracy |
±0.5ºC(0.0ºC~60.0ºC), ±1ºC(other) |
|
|
Titration |
Delay time Accuracy |
±2s |
|
Accuracy |
±2.5% |
|
|
Repeatability |
≤0.3% |
|
|
General |
Power Supply |
AC Adapter,100-240 VAC input, DC20V output |
|
Dimensions |
218×180×66 mm |
|
|
Net Weight |
0.7 kg |
|
