Capacity (L)

55

185

260

Internal Size (W × D × H) (mm)

310×380×470

500×570×650

555×570×832

External Size (W × D × H) (mm)

530×635×690

715×820×870

775×820×1055

Heating mode

Six-sided heating

Temperature control range

RT+3~60℃

Temperature uniformity

±0.25℃

Temperature fluctuation

±0.05℃

Temperature accuracy

±0.1℃

Temperature recovery (after opening door for 30s)

≤ 3 min

≤ 3 min

≤4 min

Ambient temperature range

18~34℃

CO2 sensor

Infrared (IR) sensor

CO2 concentration control range

0~20%

CO2 control accuracy

±0.1%

CO2 concentration recovery (after opening door for 30s)

≤3 min

≤3 min

≤4 min

CO2 inlet pressure

0.8~1.2bar

Humidification mode

Natural evaporation

Relative humidity range

≥90%RH

Sterilization mode

180℃ Dry heat

180℃ Dry heat

180℃ Dry heat

Sterilization duration

< 10 hours

Air intake filter

≤0.2μm

Display

7-inch LCD touch screen

Door opening method

Left and right interchange

Material

Internal

304 mirror stainless steel

External

Antimicrobial powder coating

Test hole

Φ32mm

Shelves

2 pcs

3 pcs

3 pcs

Shelf size (mm)

305×270

496×440

550×460

Shelf load (kg)

15

Power supply

115/220V, 50/60HZ

Electricity Consumption (W)

600

1300

1600

Shipping Size (W×D×H)(mm)

580x690x860

770x870x1040

835x865x1222

N.W./G.W. (kg)

60/70

85/105

110/120

Data output interface

USB, RS485

Over-temperature protection

Available

Alarm

High and low temperature alarm, gas concentration alarm, door opening alarm, fault alarm, etc.

IOT monitoring

Available
