Lamp

DC12V 22W  Tungsten halogen lamp （Lifespan up to 5000h）

Optical path

8 channel vertical light path system

Wavelength range

400-1000nm

Filter

Default configuration 405、450、492、630nm,Can be installed up to 15 filters.

Reading range

0-4.000Abs

Linear range

 0-3.000 Abs

Resolution

0.001Abs

Accuracy

≤±0.01Abs

Stability

≤±0.003Abs

Repeatability

≤0.3%

Reading Speed

Single Wavelength≤5s ;Double Wavelength≤7s

Vibration plate

Three kinds of linear vibration plate  function, Adjustable 0-255 seconds

Display

7 inch color LCD screen, display the entire board information, touch screen operation

Software

Professional software, Can store500 groups  program, 100000 sample results, More than10 kinds of curve fitting equation

Configure the inhibition rate measurement module, dedicated to the field of food safety.

PC software

equipped with professional computer-based enzyme-linked immunosorbent assay software (no additional charge)

Power input

Use the power adapter design  AC100-240V  50-60Hz

Weight

5Kg

Size

400mm（L）* 260mm（W）* 200mm（H）

Package Dimension (W*D*H)(mm)

600*440*400

G.W.(kg)

14.2KG
