Model

FNC-AS1200-1

FNC-AS1200-2

FNC-AS1200-6

FNC-AS1200-9

Temperature

Max. Temp(℃)

1200

Continuous Working Temp.(℃)

≤1100

Heating Rate

0~30℃/min, suggest to be 15℃/min;

Accuracy(℃)

±1℃

Uniformity(℃)

±5℃

Chamber Dimension (W*D*H)(mm)

100*100*100

150*200*150

200*300*200

300*400*300

External Size (W*D*H)(mm)

650*600*865mm

670*600*930mm

660*750*1020mm

830*910*1265mm

Capacity(L)

1

4.5

12

36

Heating Element

Resistance wire, Fe-Cr-Al Alloy doped by Mo

Thermocouple

K type

Chamber Material

Alumina ceramic fiberboard

Electricity

AC 220V, 50Hz/60Hz

AC380 V, 50Hz/60Hz

Gas available

all inert gases, mixed gases, nitrogen, oxygen, carbon monoxide, argon, etc.

Gas control

One or more (optional) inlets can be set at the inlet end, each inlet is equipped with a ball valve and connected to a vacuum gauge. The outlet end is connected to an outlet hole and a vacuum hole, and all holes are equipped with ball valves. Equipped with a vacuum pump.

Sealing method

The furnace door is milled with a flat surface and a silicone strip is embedded in the seal, which has strong sealing performance and is easy to open and close.

Max. Consumption

1kW

 2kW

6kW

 9kW
